NE-1050 / NE-550 / NE-551 Syringe Pumps
NE-1050 / NE-550 / NE-551 注射泵
1. Specifications
| Model | Style | Stall Detection | Number of Syringes | Maximum Syringe Size |
| NE-1050 | Stand-Alone | Yes | 1 | 60 mL; 140 mL partially filled |
| NE-550 | OEM | No | 1 | 60 mL; 140 mL partially filled |
| NE-551 | OEM | Yes | 1 | 60 mL; 140 mL partially filled |
1.1 Mechanical & Electrical
Motor type: Step motor
Motor steps per revolution: 200
Motor to drive screw ratio: 28/15
Drive screw pitch: 16 revolutions/”
Micro-stepping: 1/8 to 1/2 depending on motor speed
Advance per step: 1.8520833 μm to 7.4083333 μm depending on motor speed
Power connector: 2.1 mm, center positive, DC
Voltage at power connector: 12V DC at full load
Amperage: 1000 mA at full load
Power supply type: External wall adapter, power source specific
Power supply output rating: 12V DC @ 1000 mA
Dimensions: 8 3/4” x 5 3/4” x 4 1/2” (LxWxH) (Non-OEM versions)
(22.86 cm x 14.605 cm x 11.43 cm)
Weight:3.8 lbs. (1.63 kg)
